EV Vehicle Stack

battery · propulsion · electronics · software

An EV is seven layers that must work as one system. The bottom two layers carry most of the cost and most of the China exposure.

The EV stack in seven layers, top to bottom, with China-led layers in red: integration (vehicle OS, middleware, HMI and apps); safety and security (ISO 26262, ISO/SAE 21434, UN R155 and R156); sensing and autonomy (NVIDIA, Qualcomm, Mobileye, Horizon Robotics, Hesai lidar); low-voltage electronics (zonal controllers, microcontrollers, Ethernet, 12-volt and 48-volt systems); high-voltage electrical (onboard charger, DC-DC converter, contactors, pyrofuses, busbars); propulsion (motors, silicon carbide inverters, gearbox, e-axle); and energy storage (cells, pack, BMS and thermal, from CATL, BYD and LGES). THE EV STACK, TOP TO BOTTOM (RED: CHINA-LED SUPPLY) 7 Integrationvehicle OS, middleware, HMI, apps 6 Safety and securityISO 26262, ISO/SAE 21434, UN R155/R156 5 Sensing and autonomyNVIDIA, Qualcomm, Mobileye, Horizon; Hesai lidar 4 LV electronicszonal controllers, MCUs, Ethernet, 12V/48V 3 HV electricalOBC, DC-DC, contactors, pyrofuses, busbars 2 Propulsionmotors, SiC inverters, gearbox, e-axle 1 Energy storagecells, pack, BMS, thermal (CATL, BYD, LGES)
Layers
7
Battery share of vehicle cost
~25-35%
LV trend
48V, zonal
Hub
Supply Chain

Finding

The battery and drive unit set an EV's cost and its supply risk, while the electronics and software layers set how long it stays competitive

The pack is still the most expensive part of an EV, and with cells from CATL, BYD, LGES or Panasonic and magnets mostly from China, the bottom two layers carry most of the supply-chain exposure. The upper layers - zonal controllers, central compute, sensors and the vehicle OS - decide whether the car improves after sale through over-the-air updates.

Three shifts are running through the stack at once: 800-volt and higher power electronics on silicon carbide; zonal E/E architecture that replaces dozens of ECUs with a few zone controllers and a central computer; and 48-volt low-voltage networks, first shipped by Tesla in the Cybertruck. See Zonal Architecture and Power Electronics.

Layers

Layer by layer

Each layer lists its main parts, suppliers on both sides of the US-China divide, and the current bottleneck.

EV stack layers
LayerMain partsSuppliersBottleneck
Energy storageCells (LFP, NMC, NCA, sodium-ion), pack, BMS, battery thermalCATL, BYD, LGES, Panasonic, SK On, Samsung SDI, CALB; BMS chips from TI, ADI, NXP, InfineonCell and cathode supply concentrated in China
PropulsionPMSM, induction and wound-rotor motors; inverters; reduction gear; e-axleTesla, BYD FinDreams, Nidec, BorgWarner, ZF, Bosch, Inovance, Huawei DriveONENdFeB magnets; SiC power modules
High-voltage electricalHV harness and busbars, connectors, fuses and pyrofuses, contactors, solid-state breakers, onboard charger, DC-DCTE Connectivity, Aptiv, Amphenol, Yazaki, Eaton, Mersen, Littelfuse, Autoliv; Hongfa, VMAX (China)SiC devices; copper
Low-voltage electronics12V or 48V battery, body and zonal controllers, CAN FD, LIN, automotive EthernetInfineon, NXP, Renesas, ST, Marvell, Broadcom; Aptiv, Bosch, Aumovio; Desay SV (China)MCU allocation; Nexperia supply after October 2025
Sensing and autonomyCameras, radar, lidar, ultrasonic; ADAS and AV computer; telematics and OTANVIDIA, Qualcomm, Mobileye, Tesla; Horizon Robotics, Huawei; Hesai, RoboSense; Sony, OmniVisionLeading-edge SoCs on TSMC; US connected-vehicle rules
Safety and securityASIL-D hardware, hardware security modules, secure gateways, crash HV disconnectInfineon, NXP, Renesas; Autoliv; Vector, ElektrobitCertification effort for every software change
IntegrationVehicle OS and middleware, infotainment, apps, digital keyTesla, Rivian-VW, Android Automotive, QNX, Huawei HarmonyOS, Xiaomi HyperOSSoftware talent and integration time

V2X

Bidirectional charging and V2X

Vehicle-to-grid is a charging function, not a radio; V2V and V2I are radios.

V2X functions
FunctionWhat it needsStatus
Vehicle-to-home and vehicle-to-gridBidirectional onboard charger or DC charger, ISO 15118-20Shipping in GM, Ford, Hyundai, Kia, Tesla Cybertruck, BYD and NIO models
Vehicle-to-vehicle and infrastructureC-V2X radio on the 5.9 GHz bandDeployed in China; limited US and EU rollout

Sources

Sources and scope

Scope
EV Vehicle Stack
Sources
Company disclosures; ISO, SAE and UNECE standards
Updated
October 2026
